SSYJ04-1800
Glazing Bead Saw for uPVC Window and Door |
 |
| Technical Parameter: |
| Working air pressure |
0.4กซ0.6MPa |
| Air consumption |
80L/min |
| Voltage/ frequency |
380V/50 Hz |
| Input Power |
2.2(1.1กม2)KW |
Motor rotative velocity
|
2800r/min |
| Processing range(length) |
400-1800mm |
| Dimension |
6600mm*2100mm*1350mm |
| Net weight |
400KG |
|
|
| Technical
Analysis |
| This machine can complete processing procedure of cutting
and grooving glazing bead at the same time. It has special-purposed
measure mechanism. At first, you put window or door on the worktable,
the right inner side of the window or door should learn against
the right locating plate, the left locating plate should learn
against the left inner side of window or door, then lock the
towing plate tightly. and at this time you can process glazing
bead according to the practical length. That guarantees the
preciseion of the sizes, and avoids the error. |
|
|
