SSQJ05-120
uPVC Window and Door V-Corner Cleaning Machine |
 |
| Technical Parameter: |
| Working
air pressure |
0.4¡«0.6MPa |
| Air consumption |
150 L/min |
| Profiles
height |
40¡«120 mm |
| Profiles width |
40¡«120 mm |
| Cutting width |
3mm |
| Cutting depth |
0.3mm |
| Dimension |
930mm¡Á690mm¡Á1300mm |
| Weight |
112 KG |
|
|
| Structure Feature |
| This machine is mainly made up of
the machine frame,clamping mechanism,machine head and pneumatic
route etc.So the structure is compact.The profile clamping mechanism
is made up of the pressing cylinder,swing pole,pressing tool,short
pressing pole and the location-restricting pole.It can guarantee
the profile pressed tightly.It features pneumatic pressing,pneumatic
drive.Only by once clamp adjustment,it can finish the cleaning
of the up and down welding seam. |
| Function
Explanation |
| The machine is used for PVC door and window
transom "V" or "+"shaped welding cleaning
work.It features advanced technology,reliable function and easy
operation. |
| Special
hint |
| This machine has improved on the
pressing location,which makes the profile pressed well. If the
customers want to clean "+" welding seam,can purchase
corresponding pressing device. |
|
|
