SSM600
Small Glass Edge Grinding Machine
Technical Parameter:
Input voltage source

380v/ 50 Hz or others
Total power 3.84 kw
Quantity of grinder head 4
Max size of glass sheet 600mm*600mm
Min.size of glass sheet 25mm*25mm
Processing thickness of glass 1-8 mm
Working speed 0-3m/min
Dimension 2200mm*1200mm*1100mm
Weight 550 KG
Function Explanation

This machine is used to grind the angle edge of glass sheet. It has 4 grinder heads, one for coarse grinding,one for careful grinding,another two for angle grinding. Good angle edge effect, also easy to operation.
