| SSLJ01-350
Single head cutting Saw for Alu & PVC Profile(manual type) |
 |
| Technical Parameter: |
| Voltage/ frequency |
380V/50 Hz or others |
| Input Power |
1.1kW |
| Saw blade diameter |
350mm or other size against request |
Saw blade rotative velocity
|
3136 r/min |
| Max Height of cutting section size |
115mm |
| Max Width of cutting section
size |
(normal) 120mm |
| (against your request) not limited |
| Cutting angle range |
-20 -> 90 -> 45 |
| Dimension |
560mm*560mm*860mm |
| Weight |
80KG |
|
| Technical
Analysis |
| This
saw is used for aluminum & PVC profile cutting. It can cut
wide angle range from -20-90-45 degree. Against
your request, the cutting section width can be made to very
big size. 2-button
security design,easy operation,and reliable quality.
|
|
|
