SSHLKP4-180*2000*3000
CNC Vertical uPVC Window & Door 4-Corner
Welding Machine |
 |
| Technical Parameter: |
| Working
air pressure |
0.5¡«0.8MPa |
| Air consumption |
200 L/min |
| Input
Voltage |
380V/ 50 Hz |
| Input Power |
9.0 KW |
Welding
height
|
20¡«180 mm |
| Welding width |
120mm |
| Welding
range(length¡Áwidth) |
400¡Á400¡«3000¡Á2100
mm |
| Dimension |
5000mm¡Á1728mm¡Á2870mm |
| Weight |
3500 KG |
|
|
| Structure Feature |
| This machine is made up of four heads,fixed
pole,active pole,machine frame,electricity control box,etc.The
machine head is made up of location heating mechanism,horizontal
pressing mechanism and vertical pressing mechanism,etc.The double
left heads are installed on the fixed pole and can be opened
and closed along the fixed pole through the driving of servomotor.The
double right heads are installed on the movable pole and can
be opened and closed along the movable pole through the driving
of servomotor.The right two heads can be opened and closed relatively
to the left two heads along the horizontal beam through the
driving of the servomotor.The location-heating mechanism can
realize the location and the heating.The up and down clamp can
realize the pressing. |
| Function
Explanation |
| The machine can weld the door and window
automatically at one step after pressing the button-"automatic
run".And it enables a one-step welding for rectangular
window frame and can transport the work piece to the next processing
procedure.The control system adopts imported industrial control
computer(Chinese show,movable draw and color screen with touch),which
is possible to input the window frame of various sizes and the
processed quantity.The driving system adopts imported servomotor,which
transfer motion through one-step belt.It can realize the motion
of the four heads at the same time.It is high reliability and
wide processing range.It features easy operation,high efficiency
and is suitable for batch production. |
| Special
Hint |
| The machine features high technology,reliable
function,beautiful outlook,high precision ,easy maintenance,long
service life etc.And adopts pneumatic driving,imported SMC pneumatic
spares linear walking stand CM non-oil lubricating bearing.The
operation parts adopt the product of a famous company of Taiwan,which
is a leading firm in the field of industrial control.The operation
screen is very easy to operate,auto visual,with big capacity
of information.The driving system also adopts imported product. |
|
|
