SSHJ02-4500¡¤4/4¡¤A
uPVC Window and Door 4-head Seamless Welding
Machine |
 |
|
| Technical Parameter: |
| Working
air pressure |
0.5¡«0.8MPa |
| Air consumption |
200 L/min |
| Input
Voltage/frequency |
380V/ 50 Hz |
| Input Power |
4.5 KW |
Welding
height
|
20¡«90 mm |
| Max Welding width |
max 120mm |
| Welding
size |
400¡«4500 mm |
| Dimension |
5500mm¡Á1000mm¡Á1700mm |
| Weight |
1400 KG |
|
| Structure Feature |
| This machine is made up of four
heads, frame, electric controller box, profile-holding frame,
etc. The left head can move 20mm by following the track. Every
head has their separate location structure, pressing structure,
heating structure and head box. |
| Function
Explanation |
Welding and surface cleaning at one time, economic
and save time.
This machine is one of the necessary equipment for processing
PVC Window and Door. It can complete the whole welding alone.
It features advanced technique, pneumatic drive, PC control,
stable capability and simple operation. The CM non-oil lubricating
bearing and liner moving bearing make high precision and convenient
maintaining. The machine has one head that can weld various
angles. The four heads can work individually and jointly.
It enables welding for such shapes as ©» ©Ç ©× ©³©· ©×©× ©×©×©ï ©ï©ï etc.
|
| Special
Hint |
| The four heads can be combined at
will. |
|
|
