SSHD01-120
uPVC Window and Door Single Head Variable
Angle Welding Machine |
 |
| Technical Parameter: |
| Working
air pressure |
0.5¡«0.8MPa |
| Air consumption |
50 L/min |
| Input
Voltage/frequency |
220V/ 50 Hz |
| Input Power |
1.2 KW |
Welding
height
|
20¡«110 mm |
| Max Welding width |
max 160mm |
| Max
cutting size of profile welded |
330 mm |
| Dimension |
960mm¡Á900mm¡Á1460mm |
| Net
Weight |
260 KG |
|
|
| Structure Feature |
| This machine is made up of machine
head,machine frame,electric controlling box and supporting shelf
ect.There are orientating mechanism,pressing mechanism and heating
mechanism etc. |
| Function
Explanation |
| The machine is used for PVC door and window
welding processing with variable angle ranging from 30°-180°.It
features PC control,pneumatic driving,reliable function,simple
operation and convenient maintenance. |
|
|
