SSDJ-2045(full pneumatic type)
Extruder for Dual-component Sealant

Main technical parameter:
Full pneumatic type
Input Air pressure
0.4-0.6MPa
Air consumption
800L/min
Air motor's pressure
12-28MPa
Max Extruding output
60kg/h
A and B sealant's Mixture ratio
8:1กซ13:1
Pump A platen diameter
ø565mm
Pump B platen diameter
ø285mm
Dimension
1100mm*770mm*1700mm
Weight
350 kg
Structure Feature Function Explanation
This extruder is the full pneumatic type extruder. It is made up of air motor A, air motor B, lift & down structure A, lift & down structure B, machine framework, pneumatic system. Adopted the newest technology and design, the whole machine's installation and maintenance are very convenient and economic.
This extruder is the special machine for spreading dual-component sealant. It is full pneumatic type and do not need electric supply, can be easy to move and operation in the building site. Easy operation, easy maintenance, stable working, high efficiency, It can suit the request of insulating glass & glass curtain wall batch production.
