SLJZ-400 Multi-function Single Head Saw for Aluminum and uPVC Profile Technical Parameter: Working air pressure 0.5～0.8MPa Input Power 2.2kW Voltage/ frequency 380V/50 Hz Saw blade diameter 400mm Saw blade rotative velocity 2800 r/min Max cutting width 45°: 220mm 90°: 300mm Max cutting height 150mm Cutting angle range any degree angle between -20°,90°, 20° Max moving distance of board plate 100mm Dimension 740mm*700mm*1400mm Weight 320KG Structure Feature Function Explanation      This machine features pneumatic drive, linear and steady feeding.The saw blade is raised from bottom to up to cut profile.The cutter is alloy saw plate with high precision and long service life.It also features hard structure and stable capability.      This machine is used for aluminum and PVC profile cutting, also for curtain wall.It features wide cutting angle range from -20 to +20 degree, also wide cutting section size.
