Automatic Sealed Insulating Glass Product Line (Vertical)
Technical Parameter:
\machine type
SBLX-1600P
SBLX-1800P
SBLX-2200P
SBLX-2500P
SBLX-2700P
Input Voltage/frequency
380V/ 50Hz
380V/ 50Hz
380V/ 50Hz
380V/ 50Hz
380V/ 50Hz
Total power(kw)
17
20
24
40
50
Work speed(m/min)
2-6
2-10
2-10
2-10
2-10
Minimal processing glass size(Length*Height)mm
400*300
420*420
450*450
450*450
450*450
Maximal processing glass size(Length*Height)mm
2000*1600
2500*1800
3000*2200
3000*2500
3500*2700
Maximal insulating glass thickness(mm)
40
50
50
55
60
Above machine picture is only for reference.
